Patriarch Single Tube Radiographic

Patriarch offers High Frequency, DSP Technology at a 60Hz price

Features:

Excellent Accuracy, Reproducibility and Linearity
Automatic Calibration
Pulse Width Modulated with Closed Loop Feedback
Self Diagnostics with Error Code Reporting
Low Speed Rotor
APR Console included
Bucky Control included
Automatic Line Compensation
Large X-ray Tube Library
Software Configurable
ISO 9001:2000 with Design, CE Mark and UL 2601 Certification
FDA Approved

Utilizing DSP software control of the kVp waveform, Patriarch produces a square wave output with excellent linearity and reproducibility. The coefficient of variation between adjacent stations is less than 1%. Standard features included on all Patriarch generators are Self-Diagnostics with clearly defined Error Codes to guide the Service Technician, as well as AUTOCAL to increase productivity and reduce installation time. X-Ray tube characteristic curves are digitized and factory pre-loaded to provide ease of selection on installation as well as tube protection during operation. With step-by-step instructions from the Technical Manual the Patriarch generators are designed for a minimum of installation time. Opening the box to finishing calibration usually takes two hours or less. Using AUTOCAL, calibration takes less than 15 minutes.

Models Available: Patriarch 400, 500, 600
